| ADVANCED LCD |
| |
|
|
| ----------------------------------------------------------------------------------------------------------------------------------------------- |
| Advanced LCD Operational Features : |
| -------------------------------------------------------------------------------------------------------------------------------------------------- |
- LCD with backlight Display of battery status, operation mode, feature status etc.
- Advanced Micro-processor technology with integrated electronic circuit.
- Push to On / Off switch.
- Operations in Continuous mode (continuous on of light) by switch.
- Operations in Manual flash mode (On of light for a second) by switch.
- Operation in Timer mode (On of light for pre-determined time period) by switch.
- Dimmer (to adjust light intensity from 0 to 100%) by rotating knob.
|
|
|
- Variable Timer : to adjust light operation duration, from 30 seconds upto 15 minutes , by rotating knob.
- Auto flasher (to adjust blinking of light/flashes from 8 / second to 5 flashes/minute, by rotating knob.
- Inbuilt universal charger from 70-270 V AC.
- Option to activate / deactivate the Emergency Light feature.
- Tri-Colour LED's for indicating charging status and battery status in use.
|
|
| |
| Standard Dimensions- Non Detachable Type Light |
Model No. |
Halogen Bulb |
Sealed battery |
Length (mm) |
Dia (mm) |
Weight (kg) |
Duration of Operation |
Full Glow |
Min. Glow |
|
Lotus
551207 |
Lotus
551212 |
Lotus
1001212 |
|
|
| 12 V 7.6Ah |
| 12 V 12Ah |
| 12 V 12Ah |
|
|
|
|
|
|
|
|
| |
| Light Properties |
| ----------------------------------------------------------------------------------------------------------------------------------------------- |
- Beam of light Reaches approx.1 Km distance in clear weather conditions.
- Easily detects group of persons at 350 metres.
- Lux value at 350 metres distance of :
- 55 watt bulb: 8 lux (approx )/ 1 million c.p. at 5m.
- 100 Watt bulb: 16 lux (approx)/ 2 million c.p. at 5m
|
| |
|
|
|
| Physical Features (of all series & models) |
| ----------------------------------------------------------------------------------------------------------------------------------------------- |
- Nylon Glass filled Heavy duty body with avg. wall thickness 2.5 mm.
- Option also available with ABS & Polycarbonate material.
- Halogen Bulb with Deep Parabolic reflector.
- Reflector front glass does not crack when droplets of water fall on it when lights is on.
- Standard Rechargeable Sealed Maintenance Free Lead Acid Battery.
- Optional Nimh, Li-on, Ni-cd battery also available.
- Integrated handle with Nylon Strap for shoulder resting.
- Integrated Electronic Circuits with inbuilt charger and programmable micro-processor controlled circuit.
- Water resistant, shock resistant, crack resistant body.
- It is ideal product for applications where high quality and intensity light is essentially required.
- The HHSL is light in weight, easy to carry with multiple charging options.
- HHSL can be customized in colours
|
|
| |
| Application |
| ----------------------------------------------------------------------------------------------------------------------------------------------- |
1. Army/Paramilitary/Security forces (for border patrolling/checking/mounting of vehicles/special tasks/compound security).
2. Police (for VIP security/routine checking/special searches ), Electricity Dept., (repairs & maintenance, emergency duties).
3. Fire Brigades : (Emergency operations), Office-Factory security, Field Projects.
|
|
|
|
| |
|
|
|
|
|
| * Design, Specification subject to change without notice. |
|
|
| |
|
|
